● 24VDC or 36VDC power supply
● Command source: simple switch signal, or I/O signal of PLC, or 0-10V analog input
● 24V logical voltage for motor start/stop and motor direction.
● Output current 8.4A for single-axis, 4.2A per motor for dual-axis
● Matched with NEMA 23, 24 stepper motors
● Suitable for speed control applications
The DM series consists of stepper drives adopting Leadshine latest advanced stepper control technology. Those stepper drives are highly reliable with good performance and highly competitive cost. They can power a wide range of stepper motors from NEMA 8 to NEMA 34 (model dependent). DM-E stepper drives are easy to configure and setup. Output current and micro step resolution can be simply set up via DIP switches.
