2 phase, NEMA 34 frame size
173 mm (6.81 inch) long
6 A phase current
8.0 N.m (1133 oz-in) holding torque
14 mm (0.551 inch) shaft size
24 VDC brake
High precision, low motor heating, and low noise
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
The CS-M series closed loop stepper motors are integrated with a 1,000 line (4,000 counts/revolution) or 5,000 line （20,000 counts/revolution） differential ended rotary encoder. Build with high quality materials including bearings and shaft made by famous manufacturers, this closed loop stepper motor can be adopted in many industrial applications with excellence performance such as high precision, low motor heating, and low vibration.
